Electrochemical C2H5OH Alcohol/Ethanol/Methanol Gas Sensor/Probe Cost FS00700A
- Low power consumption, long lifespan
- Low cost, small size
- High sensitivity to low concentration of polluted gases
- Simple application circuit
- High consistency
Introduction Of Electrochemical C2H5OH Alcohol Gas Sensor FS00700A
FS00700A is an alcohol sensor probe based on electrochemical principles that works by the oxidation and reduction reactions on the working electrode and counter electrode, releasing charges to form a current. The magnitude of the current generated is proportional to the concentration of alcohol and follows Faraday’s law. By testing the magnitude of the current, the alcohol concentration can be determined.It utilizes precise automated production and testing equipment to reduce human interference, ensuring high accuracy and consistency of data even during large-scale production. This alcohol content sensor probe is particularly suitable for portable product applications as it has a compact design that is convenient for integration.
Therefore, ethanol sensor is widely used in many areas, such as hospital, school, alcohol detector, all kinds of gas anglyser and so on. Now methanol probe is vey popular around the world.
Video Of Electrochemical Alco Sensor
Features Of Electrochemical Alco Sensor
1.Small size and simple circuit.
2.Reliable data at high and low temperatures.
3.High sensitivity and fast response.
4.Long service life
5.Supports secondary development and is easy to use.
Specifications Of Alcohol Gas Sensor
Detecting Gas | Alcohol |
Detection Range | 0~1.0mg/L |
Maximum Load | 2.0mg/L |
Response Time | ≤20s |
Sensitivity | （6±2）µA/(mg/L) |
Repeatability | ±0.006mg/L |
Long-term Stability | ≤2% /Month |
Zero Drift | -0.01 mV～0.01mV (-20℃~40℃) |
Recommended Resistance | 10Ω |
Operating Temperature | -20℃～50℃ |
Operating Humidity | 15%~90% RH (non-condensing) |
Pressure Range | ±10% standard atmospheric pressure |
Storage Temperature | 0~20℃ |
Service Life | 2 years (in air) |
How To Design Alcohol Content Sensor In Fosensor
Application Of Alcohol Probe
1.Alcohol tester, instrumentation
2.Air quality tester and module
3.Portable Alcohol Detector, Gas Analyzer
4.Air purifier etc.
